Frame
CF3 carbon, race geometry. Internal cable routing, 12mm through axles, flat mount rear brakes with Disc Cooler, 1 1/2 to 1 1/4 headtube. Max tyre - 30c
Fork
Scultura CF3 Disc; Material - carbon; Max. tyre size: 700 x 30c; Disc cooler technology
Headset
FSA ACR
Stem
FSA SMR ACR; aluminium; -6 degree rise. Stem length: 90mm (XXS/XS), 100mm (S), 110mm (M), 120mm (L/XL)
Handlebar
Merida Expert SL; aluminium; Width: 380mm(XXS), 400mm (XS-S), 420mm (M), 440mm (L-XL)
Grip
Merida Road Expert
Brake Type
Hydraulic disc
Brake Lever
Shimano Ultegra
Brake Calipers
Front: Shimano Ultegra; hydraulic disc brake caliper with Shimano MT800; 160mm rotor Rear: Shimano Ultegra; hydraulic disc brake caliper with Shimano RT800; 160mm rotor
Tyres
Front: Continental Grand Sport Race; 700 x 28c; Kevlar bead, folding; Rear: Continental Grand Sport Race; 700 x 28c; Kevlar bead, folding;
Wheel Size
700c
Wheels
Rims: Part of wheelset - Fulcrum Racing 800 DB; 19mm inner rim width; 34mm depth; aluminium; Tubeless ready (tubeless tape and valves not included) Spokes: part of wheelset Front Hub: Part of wheelset - Fulcrum Racing 800 DB; 100x12mm; Center lock; With Merida Expert SL axle Rear Hub: Part of wheelset - Fulcrum Racing 800 DB; 142x12mm; Center lock; . With Merida Expert SL axle; including removable lever; 6/4mm allen key
Speeds
22
Front Derailleur
Shimano Ultegra
Rear Derailleur
Shimano Ultegra; GS
Shift Levers
Shimano Ultegra Disc
Chain
KMC X11
Cassette
Shimano CS-R7000; 11-30 teeth; 11 speed
Chainset
Shimano Ultegra; 50-34 tooth chainset. Crank length: 165mm (XXS,XS), 170mm (S), 172.5mm (M), 175mm (L,XL)
Bottom Bracket
Shimano BB71-41B, Pressfit 86.5
Pedals
Not included
Saddle
Merida Expert SL; V-mount; including Merida minitool
Seat Post
Merida Expert CC; Carbon; 27.2mm diameter; 15mm lay back
