Frame
CF3 IV - carbon with the same geometry and aeroydanmic profiling as the CF5 IV with a more budget friendly carbon lay up. Tapered headtube, BB86 BB standard, 142 x 12mm axle standard. Maximum tyre clearance 700 x 30c
Fork
Reacto CF3 IV Disc; full carbon, tapered steerer. Max. tyre size: 700 x 30c
Headset
FSA ACR
Stem
FSA SMR ACR; aluminium; -6 degree rise. Stem length: 90mm (XXS/XS), 100mm (S), 110mm (M), 120mm (L/XL)
Handlebar
Merida Expert CW, aluminium; Width: 380mm (XXS); 400mm (XS-S); 420mm (M), 440mm (L-XL)
Grip
Merida Road Expert
Brake Type
Hydraulic disc
Brake Lever
Shimano Ultegra
Brake Calipers
Front: Shimano Ultegra; hydraulic disc brake caliper with Shimano MT800; 160mm rotor Rear: Shimano Ultegra; hydraulic disc brake caliper with Shimano MT800; 160mm rotor
Tyres
Front: Continental Grand Sport Race; 700 x 25C; Kevlar bead; folding Rear: Continental Grand Sport Race; 700 x 25C; Kevlar bead; folding
Wheel Size
700c
Wheels
Rims: Part of wheelset - Fulcrum Racing 800 DB; 19mm inner rim width; 34mm depth Spokes: Part of wheelset Front Hub: Part of wheelset - Fulcrum Racing 800 DB; 100x12mm; Center lock Rear Hub: Part of wheelset - Fulcrum Racing 800 DB; 142x12mm; Center lock
Speeds
22
Front Derailleur
Shimano Ultegra
Rear Derailleur
Shimano Ultegra; GS
Shift Levers
Shimano Ultegra Disc
Chain
KMC X11
Cassette
Shimano CS-R7000; 11-30 teeth; 11 speed
Chainset
Shimano Ultegra; 52-36 tooth chainset. Crank length: 165mm (XXS,XS), 170mm (S), 172.5mm (M), 175mm (L,XL)
Bottom Bracket
SM-BB72-41B, Pressfit 86.5
Pedals
Not included
Saddle
Merida Expert CC; V-mount including Merida multitool
Seat Post
Merida Team CW; Aero shape; 15mm lay back; Carbon with intergrated rear light and battery
