Frame
Spark Carbon HMF Integrated Suspension Technology Flex Pivot, Adjustable head angle Syncros Cable Integration System BB92, UDH Interface, 12x148mm with 55mm Chainline
-
Fork
FOX 36SL Float Performance Elite Air Grip SL 3-Modes, Kabolt 15x110mm Axle 44mm offset, tapered steerer, Reb. Adj., Lockout 140mm travel
-
Rear Shock
FOX NUDE 6T EVOL Trunnion SCOTT custom w. travel, geo adj. 3 modes: Lockout-Traction Control-Descend Low Speed Adj., Custom large Air volume, Reb. Adj. Bearing Hardware, Travel 120-80-Lockout, T165X45mm
-
Remote System
SCOTT TwinLoc Technology Suspension & Dropper Remote 3 Suspension modes
-
Rear Derailleur
Shimano XT Di2 RD-M8250 SGS, 12 Speed Wireless Electronic Shift System
-
Shifters
Shimano XT Di2 SW-M8250-IR Ispec EV clamp
-
Crankset
Shimano XT FC-M8200-1 Hollowtech 2 55mm CL, 32T
-
Chainguide
SCOTT custom
-
BB-Set
Shimano XT BB-7141, shell 41x92mm
-
Chain
Shimano XT CN-M8100
-
Cassette
Shimano XT CS-M8200-12, 10-51 T
-
Brakes
Shimano XT M8220 4 Piston Disc
-
Rotor
Shimano RT-CL700 , F&R 180mm
-
Handlebar
Syncros Fraser iC SL DC Carbon, 0° rise, back sweep 8°, mini Rise, 760mm Syncros Performance XC lock-on grips
-
Seatpost
S size 110mm, M size 140mm, L size 160mm, XL size 180mm Syncros Duncan Dropper 1.5S, Travel Adjust, 31.6mm
-
Seat
Syncros Tofino 1.5 Regular Titanium rails
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
-
Wheelset
Syncros Silverton 2.0-30 CL F: 15x110mm, R: 12x148mm 30mm Tubeless ready rim 28H, MS Driver Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools
-
Front Tire
Maxxis Forekaster, 29x2.4", 60TPI Foldable Tubeless Ready, EXO 3C maxx Terra
-
Rear Tire
Maxxis Forekaster, 29x2.4", 60TPI Foldable Tubeless Ready, EXO 3C maxx Terra
-
Extras
Shimano Di2 Powerpack
-
Accessories
Tire Sealant
-
Approx weight in KG
12.6 (Tubless setup)
-
Approx weight in LBS
27.78 (Tubless setup)
-
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
