Frame
Lite - 6066 triple butted hydroformed and smooth welded aluminium with internal cable routing. Tapered head tube, Inboard disc mounts. BB86 BB standard, 142 x 12mm axle standard, Maximum tyre clearance 700 x 38c / 650b x 45c
Fork
Silex CF2; Full carbon; tapered steerer, 100 x 12mm axle standard; Max. tyre size: 700 x 38c / 650b x 45c
Headset
Merida M2331 Neck
Stem
Merida Expert CW; aluminium; 31.8mm diameter; -8 degree rise - Stem length: 80mm (all sizes)
Handlebar
Merida Expert GR; aluminium; Width: 400mm (XS-S), 420mm (M), 440mm (L/XL)
Grip
Merida Road Expert
Brake Type
Hydraulic disc
Brake Lever
Shimano GRX810
Brake Calipers
Front: Shimano GRX810; hydraulic disc brake caliper with Shimano RT64; 160mm rotor Rear: Shimano GRX810; hydraulic disc brake caliper with Shimano RT64; 160mm rotor
Tyres
Front: Maxxis Rambler; 700 x 38C; Kevlar bead; folding; TR; EXO Rear: Maxxis Rambler; 700 x 38c; Kevlar bead, folding; TR; EXO
Wheel Size
700c
Wheels
Rims: Merida Expert CX; 19mm inner rim width; 24mm depth; Aluminium Spokes: Double Butted Black stainless Front Hub: VP CLK170F; 100x12mm; 32 spokes; Center lock Rear Hub: VP CLK270R; 142x12mm; 32 spokes; Center lock. With Merida Expert SL axle; including removable lever; 6/4mm allen key
Speeds
22
Front Derailleur
Shimano GRX810
Rear Derailleur
Shimano GRX810
Shift Levers
Shimano GRX810
Chain
KMC X11
Cassette
Shimano CS-HG700; 11-34 teeth; 11 speed
Chainset
Shimano GRX810; 48-31 tooth chainset. Crank length: 170mm (XS,S), 172,5mm (M), 175mm (L,XL)
Bottom Bracket
Shimano SM-BB71-41B, Pressfit 86.5
Pedals
Not included
Saddle
Merida Comp SL; V-mount; including Merida minitool
Seat Post
Merida Expert CC; carbon; 30.9mm diameter; in-line
