FRAME - CF5 IV - The highest quality fibres for minimum weight, aggressive Pro-Tour geometry and extensive aerodynamic profiling. Disc Cooler, BB86 BB standard, 142 x 12mm axle standard. Max tyre clearance 700 x 30c
FORK - Reacto CF5 IV Disc; full carbon, tapered steerer. Max tyre size: 700 x 30c. Disc cooler technology
SHIFTERS - Shimano Dura Ace disc Di2
FRONT DERAILLEUR - Shimano Dura Ace Di2
REAR DERAILLEUR - Shimano Dura Ace Di2
BOTTOM BRACKET - Shimano BB92-41B, Pressfit 86.5
CHAIN - Shimano CN-M9100-12
CHAINSET - Shimano Dura Ace; 52-36 tooth chainset; Power Meter. Crank length: 165mm (XXS), 170mm (XS), 172.5mm (S,M), 175mm (L,XL)
CASSETTE - Shimano CS-R9200; 11-30 teeth; 12 speed
BRAKE LEVER - Shimano Dura Ace disc
FRONT BRAKE - Shimano Dura Ace hydraulic disc brake caliper with Shimano CL900 160mm rotor
REAR BRAKE - Shimano Dura Ace hydraulic disc brake caliper with Shimano CL900 160mm rotor
GRIP - Prologo One-Touch
HANDLEBAR - Team SL 1P Integrated; carbon; Width: 400mm (XXS,XS), 420mm (S,M,L), 440mm (XL) with Garmin + GoPro/Light Mount
STEM - Team One-Piece Integrated; carbon. Length 90mm (XXS,XS), 100mm (S), 110mm (M) 120mm (L,XL)
HEAD SET - Merida Team SL; OP-203 neck
PEDAL - Not included
SADDLE - Prologo Scratch M5 with V-mount adapter; including Merida minitool
SEAT POST - Merida Team CW; Aero shape; 15mm lay back; Carbon with integrated rear light
WHEEL SIZE - 700c
RIMS - Part of wheelset - Vision Metron 60 SL Clincher TL Disc; 18mm inner rim width; 48mm rim depth; carbon; Tubeless ready (tubeless tape and valves not included)
SPOKES - Part of wheelset
FRONT HUB - Part of wheelset - Vision Metron 60 SL Clincher TL Disc; 100x12mm; Centerlock with Merida Expert SL axle
REAR HUB - Part of wheelset - Vision Metron 60 SL Clincher TL Disc; 142x12mm; Centerlock with Merida Expert SL axle including removable 6/4mm allen key
FRONT TYRE - Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead, folding; tubeless ready
REAR TYRE - Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead, folding; tubeless ready
COLOUR - Black
SEASON - 2024
