FRAME
Spark Carbon HMF, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FOR
KFOX 34 Float Performance Elite Air FIT4, 3-Modes with low Speed adj. / Kabolt 15x110mm axle, 44mm offset / tapered steerer / Reb. Adj. / Lockout, 130mm travel
REAR SHOCK
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 120-80-Lockout / T165X45mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
REAR DERAILLEUR
Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
SHIFTERS
Shimano XT SL-M8100-IR / Rapidfire Plus, Ispec EV clamp
CRANKSET
Shimano XT FC-M8120-1 / Hollowtech 2, 32T
BB-SET
Shimano SM-BB71-41A / shell 41x92mm
CHAIN
Shimano SLX CN-M7100
CASSETTE
Shimano XT CS-M8100-12 / 10-51 T
BRAKES
Shimano XT M8120 4 Piston Disc
ROTOR
Shimano SM-RT76 / 6 Bolt / F&R 180mm
HANDLEBAR
Syncros Fraser 1.5 DC Alloy 7075 D.B., mini Rise / back sweep 8° / 760mm, Syncros Pro lock-on grips
H'STEM
Syncros DC 1.5, Syncros Cable Integration System, 0° rise / 7050 Alloy / 31.8mm / 1 1/8"
SEATPOST
FOX Transfer Performance Elite Dropper Post, 31.6mm / S & M size 125mm / L & XL size 150mm
SEAT
Syncros Tofino 1.5 Regular, Titanium rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Silverton 2.0-30 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / Micro Spline, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
FRONT TIRE
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft
REAR TIRE
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip
APPROX WEIGHTS IN KG
12.3 (Tubless setup)
APPROX WEIGHTS IN LBS
27.12 (Tubless setup)
MAX. SYSTEM WEIGHT
128 kg
