2026 Scott Scale 20 Gravel Bike in Kaki Green Carbon Black

2026 SCOTT Scale Gravel 20 – Rugged, Agile, Adventure-Ready Gravel Bike

If you want a gravel bike that is built for adventure but sharp enough for faster paced rides, the 2026 SCOTT Scale Gravel 20 is engineered to deliver. With a robust alloy frame, gravel-capable drivetrain, reliable braking, and versatile components, this bike is ready for mixed roads, backroads, and everything in between.

Key Features

Frame & Construction

• Scale Alloy 6061 Custom Butted Tubing — The base frame is lightweight yet resilient, ideal for all-round gravel use with durability built in.

• Syncros Cable Integration System — Internal cable routing keeps the look clean and protects housing and lines from the elements.

• Modern Interface Standards — Equipped with BB92 bottom bracket, UDH (Universal Derailleur Hanger), 12×148 mm Boost rear spacing, and a 55 mm chainline for consistency and drivetrain efficiency.

Fork & Front Setup

• Scale Rigid HMF Fork — A rigid (non-suspension) carbon fork, offering direct steering feedback and lower maintenance overhead for gravel terrain.

• Tapered Carbon Steerer & Postmount Disc Standard — Modern fork setup for performance and compatibility.

Drivetrain & Gearing

• SRAM Eagle S70 Transmission 12-Speed — High-end wireless 12-speed system built for gravel use, with smooth, precise shifting and wide gear range (10–52 cassette) to handle both steep climbs and fast flats.

• SRAM Eagle Trigger Shifters — Ergonomic and quick for confident gear changes even under load.

• SRAM Eagle S70 Crankset — Single ring 34T chainring, DUB bottom bracket interface, and tailored chainline for gravel use.

• SRAM Eagle XS 1270 V2 10–52 Cassette — Gives you ample climbing range while keeping gear jumps manageable.

Brakes & Stopping Power

• Shimano MT401 Hydraulic Disc Brakes — Reliable hydraulic braking with strong, modulation, ideal for varied surfaces.

• Shimano SM-RT10 CL Rotors (180 mm front / 160 mm rear) — Large rotors to support confident braking performance even under load or wet conditions.

Wheels, Tyres & Rolling Setup

• Syncros X-28 TR Tubeless-Ready Rims — Lightweight, resilient rims with a 28H build, ready for tubeless setups to reduce punctures and improve comfort.

• Maxxis Aspen Folding Tires (29×2.4″) — Balanced gravel tyre option with good grip, rolling efficiency, and tread suited for mixed surfaces.

Components & Contact Points

• Syncros Alloy 6061 Handlebar (Flat 9° with 740 mm width) — Broad control and progressive ergonomics for gravel terrain.

• Syncros DC 3.0 Stem & Performance XC Lock-On Grips — Secure, precise, and comfortable cockpit.

• Syncros Seatpost (31.6 × 400 mm) — Solid, reliable post for stable fit.

• Syncros Belcarra V2.5 Cut-Out Saddle — Comfort-oriented saddle with cut-out relief and ergonomic shape.

Practical Specs & Capability

• Approximate Weight: 11.4 kg (tubeless setup, without pedals) — Very competitive for a gravel bike spec’d for durability.

• Max System Weight: 120 kg — Covers rider, gear, hydration, and extra loads.

• Versatile Mounting Options — Designed with multiple attachment points for racks, bags, and accessories so it can adapt to adventure use or long rides.

Summary

The 2026 SCOTT Scale Gravel 20 is a thoughtfully engineered gravel bike that can handle both weekend exploration and fast-paced rides. With its tough alloy frame, gravel-oriented drivetrain (SRAM Eagle S70), dependable Shimano MT401 disc brakes, tubeless-ready wheels and versatile tires, it is built to take on a wide spectrum of terrain. Whether you’re riding clean gravel roads, forest tracks, or mixed surfaces, the Scale Gravel 20 offers control, stability, and performance. Perfect for riders seeking a high-value, durable, and adventure-ready gravel companion.
