PROLITE 66 TRIPLE BUTTED ALUMINUM:
Our proven high-end aluminium (6066) is extremely light and durable. Using triple butted wall thicknesses and hydroforming technology, we can tune the aluminium tubes to give the best possible stiffness to weight ratio.
FLOAT LINK REAR SUSPENSION:
The lower shock mount moves with the system to deliver sensitive response characteristics. Our engineers can precisely influence the transmission ratio, and progression meaning a ‘Float Link’ rear suspension system appears to offer more travel than the model name suggests.
X-TAPER HEADTUBE:
Using a tapered head tube with 1 1/8" bearings in the top and 1 1/4" or 1 1/2" in the bottom creates superb stiffness and precise, confidence-inspiring steering.
SMOOTH WELDING:
Sometimes called ‘double pass welding’, a second pass over the weld gives a clean organic look to the frame. At first glance, you will be convinced it is carbon.
INTERNAL CABLE ROUTING:
Cables are routed through the frame, entering and exiting through smooth sockets. The bike looks neat, whilst the cables are protected from moisture and dirt.
SMART ENTRY:
Cables, housings and brake hoses are clamped under tension to prevent rattling when the trails or roads get rough. All inlets are completely interchangeable to deal with Di2, hydraulic hoses, brake cable and gear cable housings etc.
DOWN TUBE EXIT:
Ensures that internally routed cables and wires can’t move freely and remain easily accessible for servicing.
DI2 READY:
Bikes/frames with the symbol ‘Di2 Ready’ are prepared for the installation of Di2 technology with battery mounting in the seat post or within the fork steerer.
NON-SLIP TIGHTENING:
Selected bolts can be tightened via a TORX 30 key from just one side, without running the risk that the opposite side slips or turns, allowing faster and more straightforward tightening of important hardware components.
12-148 THRU-AXLE ‘Boost’:
New Boost standard – wider axle widths; 110 mm front and 148 mm rear, allowing a shallower spoke angle for stiffer wheels, especially beneficial in 29ers.
15-110 THRU-AXLE ‘Boost’:
New Boost standard – wider axle widths; 110 mm front and 148 mm rear, allowing a shallower spoke angle for stiffer wheels, especially beneficial in 29ers.
C-S POST MOUNT DISC:
Post mount disc brake callipers fit directly onto the seat stay for a strong and light connection whilst a chainstay post mount positions the calliper on the chainstay within the rear triangle for extra protection and better distribution of braking forces. Another benefit is that internal cable routing is also easier and neater via the chainstay.
