eBike motor | Bosch Performance Line CX Race Edition (Smart System) drive unit with 85Nm maximum torque, 250W nominal power. Features four power settings including Race Mode |
eBike display | Bosch LED Remote allows for easy use and visibility for the rider, also connecting to Bosch’s eBike Flow App to give the rider even more insight and control at their finger tips |
eBike battery | Bosch PowerTube 750Wh internal, perfectly integrated into the frame with an intuitive lockable mechanism for easy removal. Reaches full charge in less than six hours, and just over two hours for half charge. Supplied with Bosch’s 4A Compact Charger |
eBike battery charger | |
Shock, stroke and sag | |
Reducer bush widths | |
Eye to eye length | |
Weight | |
SKU part code | |
Sizes available | M, L, XL |
Colour | Gloss pearlized white with matt black |
Frame | 6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link and 12mm x 148mm Boost dropouts |
Fork | RockShox ZEB Ultimate 29in, 180mm travel, 44mm offset, DebonAir, Charger 2.1 RC2 damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle Stealth |
Rear shock | RockShox Super Deluxe Ultimate RCT, air, Fast Black coating, adjustable rebound, low speed compression adjustment and tuneable DebonAir |
Headset | FSA No. 55R/35 Orbit 1.5 ZS, 1.8in lower and 1 1/8in upper sealed cartridge Bbearings |
Rear hub | DT Swiss Hybrid HX1700, 30mm wide rim, 12 x 148mm Boost, SRAM XD steel |
Front hub | DT Swis Hybrid HX1700, 30mm wide rim, 15 x 110mm Boost |
Spokes | DT Swiss |
Rims | |
Tyres | Maxxis Assigai WT, TR, 29in x 2.5in 120TPI, EXO + sidewall protection, 3C MaxxGrip, Dual Compound, folding bead, front; Maxxis Assigai WT, TR, 27.5in x 2.5in 120TPI, Double Down casing, 3C Maxx Grip, Dual Compound, rear |
Shift Levers | SRAM AXS Pod, two button MMX, 12 speed |
Front derailleur | N/A |
Rear derailleur | |
Cassette | SRAM XS-1295 Eagle T-Type, 10-52T, 12 speed |
Chain | SRAM X0 T-Type Eagle, 12 speed |
Crankset | Race Face Affect E-Bike, 165mm, ISIS with X-SYNC Direct Mount 36T chainring for Bosch Performance Line CX, black |
Bottom bracket | N/A |
Seatpost | Crank Brothers Highline 3, 30.9mm (M/L 150mm travel; XL 170mm travel), Highline ball socket remote lever |
Seat | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail
|
Bar | Race Face Turbine R, 35mm rise, 35mm bar bore, 800mm wide |
Stem | Race Face Atlas, 35mm bar bore, 35mm extension
|
Grips | Whyte Lock-on Enduro |
Front brakes | SRAM Code RSC, four piston with sintered metal pads, 220mm disc |
Rear brakes | SRAM Code RSC, four piston with sintered metal pads, 220mm disc |
Brake levers | |
Pedals | None |
