Colour |
Matt Petrol with Lime/Mist |
Frame |
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Intergrip Seat Clamp System with Internal BBX Cable Routing for Dropper Post and 12mm X 148mm Boost Dropouts |
Fork |
RockShox Sektor RL 27.5", 130mm Travel, 37mm Offset, DebonAir, Fast Black Coating, Adjustable Compression and Rebound, Tapered Steerer, 110mm x 15mm Boost, Maxle Lite |
Rear Shock |
N/A |
Headset |
FSA No. 57B Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Caged Bearings |
Rear Hub |
Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Through Axle, 32 Hole |
Front Hub |
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Through Axle, 32 Hole |
Spokes |
DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples |
Rims |
WTB ST i35 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole |
Tyre |
Maxxis High Roller II TR 27.5" x 2.8" 120TPI, EXO Sidewall protection, 3C Maxx Terra, Front, Maxxis Rekon TR 27.5" x 2.8" 60TPI, EXO Sidewall Protection, Rear |
Shift Levers |
SRAM NX, 11 Speed |
Front Mech |
N/A |
Rear Mech |
SRAM NX, 11 Speed |
Cassette |
SRAM PG-1130, 11-42, 11 Speed |
Chain |
SRAM PC-1110, 11 Speed |
Crankset |
SRAM NX, X-SYNC Direct Mount 30T, 170mm, Boost 11 Speed |
Bottom Bracket |
SRAM GXP, 73mm |
Seatpost |
Whyte drop.it Post, 30.9mm, XS 100mm Travel, S 125mm Travel, M/L/XL 150mm Travel, Paddle Remote Lever |
Saddle |
Whyte Custom, Triple Panel Design |
Handlebar |
Whyte 6061 Alloy, 15mm Rise, 31.8mm, XS/S 760mm Wide, M/L/XL 780mm Wide (L/XL 30mm Rise) |
Stem |
Whyte Gravity Stem, 35mm Extension |
Grips |
Whyte Lock-on V Grip |
Front Brakes |
TRP Slate, 4 Pot, 180mm Rotor, XL 200mm |
Rear Brakes |
TRP Slate, 4 Pot, XS/S 160mm, M/L 180mm, XL 200mm Rotor, Internal Routing |
Brake Levers |
TRP Slate |
Pedals |
None |
Weight |
TBC |
Maximum tyre size
|
